Description
Specifications:
Part Number(s)
E864066
Enclosure Color
Black
Compatibility
M50 Mobile Computer
I/O Ports
USB-C
Dimensions
2.71″ x 5.18″ x 3.7″ / 69 mm x 131.6 mm x 94 mm
Shipping Box Dimensions
6.89″ x 5.51″ x 4.65″ / 175 mm x 140 mm x 118 mm
Mounting Options
Countertop (Refer to QIG for more details)
Weight (Unpackaged)
1.2 lbs / 0.55 kg
Weight (Packaged)
4.0 lbs / 1.8 kg
Operating Temperature
0?C to 40?C / 32?F to 104?F
Storage Temperature
-20?C to 50?C / -4?F to 122?F
Humidity
Operating: 20% – 80%
Storage: 10% – 95%
Regulatory approvals and declarations
UL, FCC (US) – Class B
cUL, IC (Canada)
CB (International safety)
CE (Europe) – Class B
VCCI (Japan)
RCM (Australia)
China RoHS
MTBF
50,000 hours demonstrated
Warranty
1-year
What’s in the Box
2x M4 screws for mounting
1x tie wrap for cable management
QIG
